Description
GENERAL DATA
|
Length
|
560 mm |
|---|---|
| Weight | 15 kg |
| Dimension / l | 560 mm |
|
Width
|
215 mm |
|
Height
|
370 mm |
| Welding current max. | 230 A |
|---|---|
| Welding current min. | 10 A |
| Welding current / Duty cycle [10min/40°C] | 210A / 30% MAG, 180A / 35% MMA, 230A / 35% TIG |
| Welding current / Duty cycle [10min/40°C] | 170A / 60% MAG, 150A / 60% MMA, 200A / 60% TIG |
| Welding current / Duty cycle [10min/40°C] | 150A / 100% MAG, 130A / 100% MMA, 170A / 100% TIG |
| Open-circuit voltage | 90 V |
| Mains voltage | 230V |
| Degree of protection | IP23 |
